Proton e.MAS 7 PHEV full specs revealed – 3 variants, up to 170km EV range
The Proton e.MAS 7 PHEV will be the first plug-in hybrid vehicle from the national car brand. While we are not allowed to show you the uncamouflaged car yet, what we can tell you is there are three variants confirmed – Prime, Premium, and Premium +. Prices have yet to be announced.
Dimensions wise the Proton e.MAS 7 PHEV measures at 4,740 mm long, 1,940 mm wide, 1,685 mm tall, 2,755-mm long wheelbase and a turning radius of 5.2 metres. Fuel tank capacity measures at 51-litres and luggage capacity measures up to 2,065-litres with the rear passenger seats folded down flat (60:40).
Among the standard exterior items on the Proton e.MAS 7 PHEV are:
- LED Headlamps
- Auto headlamps with Follow Me Home function
- Intelligent High Beam Control (IHBC)
- LED turn signal
- LED daytime running light (DRL)
- 3D Full-Length LED taillights
- Roof rails
- Auto rain sensing front wipers
- Electrically adjusted and heated door mirrors
- 225/55 R18 tyres
The Premium variant adds:
- Full-width front illuminated bar
- Powered tailgate
- Auto fold door mirrors
- 235/50 R19 tyres
The Premium + variant adds:
- Panoramic sunroof with sunshade
All three variants share the same powertrain, differing only on the battery capacity for the Premium + variant. The table below shows the full powertrain details between the three variants:
e.MAS 7 PHEV Prime | e.MAS 7 PHEV Premium | e.MAS 7 PHEV Premium + | |
Drivetrain Setup | Front Wheel Drive (FWD) | Front Wheel Drive (FWD) | Front Wheel Drive (FWD) |
Drive Mode | PURE/HYBRID/POWER | PURE/HYBRID/POWER | PURE/HYBRID/POWER |
Engine Type | 1.5L 4-cylinder Dedicated Hybrid Engine (DHE) | 1.5L 4-cylinder Dedicated Hybrid Engine (DHE) | 1.5L 4-cylinder Dedicated Hybrid Engine (DHE) |
Transmission Type | 11-in-1 Dedicated Hybrid Transmission (DHT) | 11-in-1 Dedicated Hybrid Transmission (DHT) | 11-in-1 Dedicated Hybrid Transmission (DHT) |
Max. Engine Power | 73 kW | 73 kW | 73 kW |
Max. Engine Torque | 125 Nm | 125 Nm | 125 Nm |
Electric Motor Power | 160 kW | 160 kW | 160 kW |
Electric Motor Torque | 262 Nm | 262 Nm | 262 Nm |
0 – 100 km/h | 8.0 s | 8.0 s | 8.2 s |
Top Speed | 170 km/h | 170 km/h | 170 km/h |
Battery Type | Lithium Iron Phosphate (LFP) | Lithium Iron Phosphate (LFP) | Lithium Iron Phosphate (LFP) |
Battery Capacity | 18.4 kWh | 18.4 kWh | 29.8 kWh |
DC Charging Max Power | 30 kW | 30 kW | 60 kW |
DC Fast Charging Time (30% – 80%) | Under 20 minutes | Under 20 minutes | Under 16 minutes |
AC Charging Power | 6.6 kW | 6.6 kW | 6.6 kW |
EV Driving Range (NEDC) | 105 km | 105 km | 170 km |
Total Driving Range (NEDC) | 1,000 km | 1,000 km | 1,065 km |
Fuel Consumption (L/100km – NEDC) | 4.3 km | 4.3 km | 4.4 km |
We can’t share with you photos of the interior but what we could share with you are the full details which are quite similar to its EV sibling, the Proton e.MAS 7.
Among the standard interior items on the Proton e.MAS 7 PHEV are:
- 10.2-inch LCD meter cluster
- 15.4-inch 2.5K centre console display
- Flyme Auto operating system
- Apple Carplay & Android Auto
- English & Malay language interface
- Online Navigation
- Multi-Function leatherette steering wheel
- Tilt & telescopic steering adjustment
- Leatherette Seats
- LED Boot Light
- Dual level adjustable boot floor
- 6-speaker sound system
- Keyless entry & start
- Walk away auto lock
- Manually adjustable driver and front passenger seat
The Premium and Premium + variants add:
- Auto dimming frameless rear-view mirror
- 6-way power adjustable driver seat with memory
- 4-way power adjustable front passenger seat
- Front ventilated seats
- Fully reclinable front passenger seat
- Rear central armrest with cup holders
- 265 colours ambient lighting
- Tonneau cover (retractable)
- Windshield heads-up display (HUD)
- Wireless charging
- 16-speaker Flyme sound system with headrest speaker
- Auto air-conditioning with N95 filter
A level 2 ADAS suite comes as standard for the Proton e.MAS 7 PHEV. Among the safety equipment are:
- Intelligent Cruise Control (ICC)
- Adaptive Cruise Control (ACC)
- Automatic Emergency Braking (AEB)
- Forward Collision Warning (FCW)
- Emergency Brake Assist (EBA)
- Lane Departure Warning (LDW)
- Lane Departure Prevention (LDP)
- Leading Vehicle Departure Alert (LVDA)
- Traffic Sign Recognition (TSR)
- 6 Airbags
- Auto brake hold
- Traction Control System (TCS)
- Antilock Brake System (ABS)
- Electronic Brakeforce Distribution (EBD)
- Brake Assist (BA)
- Electronic Stability Control (ESC)
- Active Rollover Protection (ARP)
- Hill Hold Assist (HHA)
- Hill Descent Control (HDC)
- Multi Collison Braking System (PIB)
- Tyre Pressure Monitoring System (TPMS)
- Regenerative braking system
- Rear parking sensors
- Rear seat passenger detection
- Reverse Camera
- Auto door lock when driving
The Premium and Premium + variants add:
- Emergency Lane Keep Assist (ELKA)
- Rear Collison Warning (RCW)
- Rear Cross Traffic Alert (RCTA)
- Rear Cross Traffic Braking (RCTB)
- Lane Change Safety Warning (LCW)
- Blind Spot Detection (BSD)
- Door Open Warning (DOW)
- 7 Airbags
- Occupant detection alert
- Front parking sensors
- 360° camera with 3D display
Any details of warranty coverage or service maintenance cost are soon to be revealed during the official launch of the Proton e.MAS 7 PHEV.
